MMA-M21 MINI Series

IGBT MINI INVERTER ARC WELDER

Instruction:

● High frequency(40KHZ-100KHZ),improve the efficiency of the whole machine,save energy.

● Pretty appearance,light weight,stable.

● Have the advantage of easily start arc,stable current,perfect molding.

● Adopt all kinds of acidic,alkaline welding rod.

● High rated duty and have better function for push compensation.

● Use for altitude work,fieldwork,indoor fitment.

Contact us

  • Product Details
  • leave a message

  • MODEL MMA-160A-MIMI-M21  MMA-180A-MIMI-M21 MMA-200A-MIMI-M21
    Rated input voltage(V) 1~230 1~230 1~230
    No-load voltage(V)  56 56 60
    Current range(A)  30-160 30-180 30-200
    Rated duty(%) 60% 60% 60%
    Input capacity(KVA)  5.3 6.1 7.1
    Class of insulation  F F F
    Weight(Kg)  3.4 3.6 3.8
    Dimension(cm) 1PC 32×17×21.5 32×17×21.5 34×17×22
    Dimension(cm) 4PCS 66.5×36.5×23.5 66.5×36.5×23.5 70.5×36.5×24
