TIG/MMA-M18 Series

IGBT INVERTER TIG/MMA WELDER

Instruction:

● Portable,fan-cooled,thermostatic protectio,starting arc with contact.

● Adopt with advanced IGBT inverter technology,lightweight,accord with EMC standard

● Stepless current adjustment,suit for TIG/MMA welding.

● Perfect with overheating,over load,over current,over/lack voltage protection.

● With complete accessories:TIG series TIG torch,earth clamp,brush/hammer,protective

● mask carton box,TIG/MMA series TIG torch,electrode holder,earth clamp,brush/hammer,

● protective mask,carton box

Contact us

  • Product Details
  • leave a message

  • MODEL TIG/MMA-180A
    -M18
    TIG/MMA-200A
    -M18
    TIG/MMA-250A
    -M18
    TIG/MMA-315A
    -M18
    TIG/MMA-400A
    -M18
    TIG/MMA-315A
    -N-M18
    TIG/MMA-400A
    -N-M18
    Rated input voltage(V) 1~230 1~230 1~230 3~380 3~380 3~380 3~380
    Rated input voltage(V) 1~110 1~110 1~110 / / / /
    No-load voltage(V)  56 56 56 60 60 60 60
    Current range(A)  10-180 10-200 10-250 10-315 10-400 10-315 10-400
    Rated duty(%) 60% 60% 60% 60% 60% 60% 60%
    Input capacity(KVA)  3.9 4.5 6.3 8.9 13 8.9 13
    Class of insulation  F F F F F F F
    Weight(Kg)  6.8 7 7.2 26 28 30 32
    Dimension(cm) 1PC 47.5×24×30 47.5×24×30  47.5×24×30  60×32×48.5  64×34×50 60×32×48.5 64×34×50
