BX1-C4 Series-Shenyuan Electro-machinery Incorporated Corporation

BX1-C4 Series

AC.ARC WELDER

Instruction:

● Single-phase,fan-cooled stick electrod welding machines for MMA-welding in alternating current(AC)stepless regulation of welding current.

● With hermostatic protection.Use the normal welding rod.

● Electrode holder,earth clamp,welding cable.

● Brush/hammer,protective mask,carton box.

Contact us

Product Details
leave a message

MODEL	BX1-130A-C4	BX1-160A-C4	BX1-180A-C4	BX1-200A-C4	BX1-250A-C4
Rated input voltage(V)	220/380	220/380	220/380	220/380	220/380
Rated input voltage(V)	110/220	110/220	110/220	110/220	10/220
No-load voltage(V)	48	48	48	48	48
Current range(A)	50-130	70-160	80-180	80-200	90-250
Rated Duty Cycle(%)	10%	10%	10%	10%	10%
Input capacity(KVA)	5.2	6.4	7.8	8.4	9.6
Class of insulation	H	H	H	H	H
Usable electrodes(mm)	2-3.2	2-3.2	2-4	2-4	2-5
Weight(Kg)	16.5	19	20	21	21.5
Dimension(cm) 1PC	50×26.5×39	50×26.5×39	50×26.5×39	50×26.5×39	50×26.5×39
